HOWO 400HP 8×4 Dump Truck
Heavy-Duty 8×4 Tipper Truck for Construction, Mining, and Bulk Material Transport
HOWO 400HP 8×4 Dump Truck
The HOWO 400HP 8×4 Dump Truck is engineered for demanding construction and mining projects, offering powerful performance, high load capacity, and reliable operation. With a 400HP engine, reinforced MAN axles, and a durable hydraulic tipping system, it provides long-lasting productivity and efficiency for heavy-duty applications.
Detailed Product Description :
The HOWO 400HP 8×4 Dump Truck (ZZ3317N3847E1) is designed to handle intensive hauling tasks across construction sites, mining operations, and large material transport projects. Powered by either the WD615.47 or WP12.400E62 engine, the truck delivers a strong 400 horsepower output and up to 1800 Nm of torque, ensuring excellent traction and load-pulling capability in challenging working environments.
A FAST 12-speed manual transmission enhances driving control, fuel efficiency, and power delivery. Supported by reinforced 9.5-ton MAN front axles, 16-ton dual-reduction MAN rear axles, and an 850×300 mm strengthened frame, the vehicle maintains high stability under full load. The multi-leaf spring suspension further boosts durability, making the truck suitable for rough terrain and long-duration operations.
The hydraulic tipping mechanism ensures fast, safe, and efficient unloading, significantly reducing downtime. Its spacious cabin features ergonomic seating, air conditioning, and user-friendly controls, providing comfort and visibility for operators. Optional features, such as WABCO braking systems and air-cushioned seats, enhance safety and overall driving experience.
Designed for long-term performance, fuel efficiency, and minimal maintenance, the HOWO 400HP 8×4 Dump Truck is widely used in Africa, the Middle East, Southeast Asia, and other regions requiring reliable heavy-duty transport solutions.
Key Advantages:
Powerful 400HP Engine: Delivers strong torque output for heavy-duty hauling.
Reinforced MAN Axles: Ensures durability and superior load-bearing capability.
Efficient FAST 12-Speed Transmission: Smooth gear shifting and optimal power usage.
Reliable Hydraulic Tipping System: Fast and stable unloading for higher productivity.
Heavy-Duty Frame Construction: 850×300 mm chassis supports demanding work conditions.
Comfortable & Safe Cabin: Equipped with A/C, ergonomic seating, and improved visibility.
Low Maintenance & Long Service Life: Built for durability in harsh working environments.
Key Specifications:
Specification | Details |
|---|---|
Brand | HOWO |
Model | ZZ3317N3847E1 |
Drive Type | 8×4 |
Engine | WD615.47 / WP12.400E62 |
Horsepower | 400 HP |
Torque | 1800 Nm |
Emission Standard | Euro II / III / IV / V |
Transmission | FAST 12-speed manual |
Clutch | 430 mm |
Frame | 850×300 mm |
Front Axle | 9.5T MAN |
Rear Axle | 16T MAN dual reduction |
Suspension | Multi-leaf springs |
Tires | 12.00R20 × 12 pcs |
Fuel Tank Capacity | 300–400 L |
Dimensions (L×W×H) | 9800 × 2500 × 3450 mm |
Wheelbase | 1800 + 2975 + 1400 mm |
Max Speed | 80–85 km/h |
Loaded Speed | 45–60 km/h |
Gradeability | 34% |
Cab Features | A/C, hydraulic seat, manual sunroof, MP3, electric windows |
Optional Equipment | WABCO system, central locking, air-cushioned seat |
Origin | China |
Delivery Time | 15–20 days |
Monthly Supply Capacity | 10,000 units |
Production & Shipping:
ZW Group supplies the HOWO 400HP 8×4 Dump Truck in both brand-new units—subject to availability—and expertly refurbished versions customized to client requirements. Each refurbished truck undergoes a comprehensive restoration process that includes full engine tuning, transmission and axle servicing, hydraulic cylinder testing, chassis reinforcement, electrical system diagnostics, and complete cabin reconditioning. Before shipping, every unit is road-tested to verify stability, performance, and safety.
For overseas delivery, all trucks are secured using professional export methods such as flatbed transport, Ro-Ro shipping, or containerized modular carriers. Critical areas—including the cabin, hydraulic components, and fuel system—are protected with reinforced straps and cushioning materials to prevent movement or impact during transit. This ensures each truck arrives at the customer’s destination in excellent condition and ready for immediate operation.
