6 Axle Coal Transport Dump Semi Trailer
High-Capacity End Tipper Semi-Trailers for Mining
Heavy-Duty 6 Axle 80 Ton Sand & Coal Transport Dump Semi Trailer
The Ultimate Solution for Bulk Haulage: High-Capacity End Tipper Semi-Trailers for Mining, Construction, and Aggregates
Product Overview: Your Reliable Partner in Heavy Transport
ZW Group 6 Axle 80 Ton Dump Semi Trailer is engineered for the most demanding transport conditions, providing a robust, high-capacity solution for moving bulk materials like coal, sand, gravel, ore, and construction aggregates.
This heavy-duty end tipper semi-trailer is a vital asset for mining operations, large-scale construction projects, and bulk logistics companies that require maximum payload and unwavering durability.
Built with advanced materials and precision manufacturing, our trailer maximizes your operational efficiency while ensuring safety and a long service life.
With a substantial 80-ton payload capacity and a highly stable 6-axle configuration, the ZW Group tipper trailer is specifically designed to handle long-distance hauling and challenging off-road environments.
It represents a top-tier investment in productivity, featuring world-class components like HYVA hydraulic lifting systems and internationally recognized axle and braking brands.
Choose ZW Group for a reliable, customizable, and high-performance bulk transport solution.
Key Product Features: Unmatched Durability and Performance
Component | Key Feature & Material |
Chassis / Main Beam | High Tensile Steel (Q345B/T700) with double-plate design. |
Axles | Genuine FUWA, BPW, or ZY 13-ton / 16-ton axles. |
Suspension System | Reinforced Heavy-Duty Mechanical (Leaf Spring) |
Tires | High-Load Radial Tires (11R22.5 / 12R22.5) |
Paint & Finish | Comprehensive Sandblasting treatment followed by Anti-Corrosion Primer and two coats of final marine-grade paint. |
Hydraulic System | World-renowned HYVA Telescopic Hydraulic Cylinder or equivalent. |
Detailed Advantages: Safety, Efficiency, and Longevity
Optimized Box Structure: The cargo box features an exceptionally thick side wall (8mm) and bottom floor (10mm), built with wear-resistant steel to withstand the constant impact of loading sand, rock, and coal.
Superior Braking System: Equipped with a Dual-line Pneumatic Braking System and a genuine WABCO ABS. This system ensures high-response braking performance under full load, drastically improving road safety and preventing tire skidding.
Safety Enhancements: Includes essential features like an emergency relay valve, LED lighting for high visibility, and a strategically placed tipping limit valve to prevent over-tipping and rollover accidents.
Landing Gear: Heavy-duty JOST brand two-speed manual landing gear provides rock-solid stability during parking and loading/unloading operations.
Kingpin: Replaceable JOST 3.5-inch or 2.5-inch bolt-in type kingpin, allowing for compatibility with various tractor trucks and ensuring easy maintenance.
ZW Group Quality Commitment: Manufacturing, Testing, and Delivery
Precision Manufacturing Process
Our commitment to quality starts with the fabrication process, utilizing cutting-edge technology and high-grade materials to construct a durable tipper semi trailer that will withstand years of heavy use.
Rigorous Load and Stability Testing
Before any dump semi trailer leaves our factory, it is subjected to an intensive quality control program to ensure it meets our exacting standards and all international safety regulations.
Product Drawings and Customization
ZW Group provides detailed technical drawings, including CAD blueprints, upon request to verify all dimensions and component specifications.
Product Configuration Parameters
Parameter | Specification |
Model | ZW9450TDP |
Max Payload | 80,000 kg (80 Ton) |
Volume (CBM) | 40 CBM - 55 CBM (Customizable) |
Overall Dimension (L*W*H) | Approx. 11,000mm – 12,500mm x 2,550mm x 3,700mm |
Axle Specification | 6 Axles, 13T/16T Capacity each (FUWA/BPW) |
Tire Specification | 24 units, 11.00R20 / 12.00R20 / 12R22.5 |
Main Beam Material | Q345B/T700 High-Strength Steel |
Kingpin | JOST Brand 3.5'' (90#) or 2.0'' (50#) Bolt-in Type |
Hydraulic System | Full set HYVA Telescopic Lifting Cylinder (5 Stage) |
Brake System | Dual Line Air Brake, WABCO Relay Valve |
Landing Gear | JOST 28 Ton Two-Speed |
FAQ: Frequently Asked Questions
Q1: What is the warranty period for the ZW Group 6 Axle Dump Semi Trailer?
A: We offer a one-year warranty on the main structural frame (chassis/main beam) and a six-month warranty on major components like the hydraulic cylinder (HYVA), axles (FUWA/BPW), and landing gear (JOST) against manufacturing defects.
Q2: Can I customize the payload and number of axles for my specific market regulations?
A: Absolutely. Our dump semi-trailers can be customized to meet local GVW (Gross Vehicle Weight) and GVM (Gross Vehicle Mass) regulations.
Q3: Is the HYVA hydraulic lifting system essential for the 80-ton capacity?
A: Yes. We recommend the HYVA telescopic cylinder as it is a globally recognized leader in stability, lifting power, and longevity, which is crucial when tipping a fully loaded 80-ton bulk material trailer.
Q4: How does the sandblasting and painting process improve the trailer's lifespan?
A: The sandblasting process prepares the steel surface for superior paint adhesion, removing all impurities. The application of a zinc-rich anti-corrosion primer creates a rust-resistant barrier. This multi-layer professional finish is vital for preventing rust in harsh, corrosive environments like those transporting coal, sand, or salt, thereby significantly extending the trailer's service life.
Q5: What is the lead time for production and delivery?
A: Standard production time is typically 30-45 working days, depending on current order volume and required level of customization. Shipping time is determined by the final destination port and shipping method chosen (RORO, Bulk, or Container).
